Top Arm Load Gauge Sun Tarp Gauge

Top Arm Load Gauge Sun Tarp Gauge
Send Inquiry
Product Code : STG
Brand Name : SUNRISE
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Set/Sets
  • Price
  • 15000 INR
Product Specifications
  • Usage
  • RING FRAME IN TEXTILE INDUSTRY
  • Capacity
  • 30 Kilogram(Kg)
  • Machine Weight
  • 1 Kilograms (kg)
  • Dimensions
  • 12 X 12 X 3 Inch (in)
Product Description

SUN TARP GAUGE ( TOP ARM LOAD GAUGE )    measure Top Arm Roller Pressure (load) infront, middle & back rollers of all types of drafting systems used today inRing Frames & Speed Frames, such as SKF PK 225, 2025, 235, 211, 1500, 1600,1601, 704, BM 12, 14, 15, RIETER G5/1, G6, DJ5, LF 1400, LF 1400A, SUESSEN WSTUT 620, UTM 620, UTS 200, etc.

The top rollers are loaded at specificlevels & thus uniformity between top arms on the same frame is maintained.In the course of continuous working, however, variations occur from the setloads which affect the quality of drafted materials. Low top arm loads resultsin undrafted yarn, unevenness & hence affect the strength & count CV% .Excess loads also squeeze the cots & increases the power factor of themachines. Hence, frequent methodical check up & corrections of top rollerloads is necessary. The instrument is suitable for cots from 25mm to 75mmdiameter  with least count of 0.5 kg andmax. 350 kgs. It is also suitable for wool/worsted  ring spinning frames like as Cognetex, NSC,& jute spinning  like Mackie, DASN,  etc.


SUN TARP GAUGE ( TOP ARM LOAD GAUGE )  -  LOAD SETTING VALUES FOR RING FRAMES & SPEED FRAMES (kg)

Name of Drafting

Front Roller Load

Middle Roller

Rear

Rear

SKF PK 225*10 Black--

--

--



14 Green10

14

--

18 Red--

--

--

SKF PK 21187

5.4

--

LR G5/11614

16

--

LR DJ/51410

14

--



SKF PK 1600-40*20 Black10

10

10



25 Green15

15

15



30 Red20

20

20

WST UT M 6201612

14

14

LR LF 14002012

16

16

LR LF 1400A20

12

16

--

Trade Information
  • FOB Port
  • AHMEDABAD
  • Payment Terms
  • Western Union, Telegraphic Transfer (T/T), Cheque, Cash in Advance (CID), Cash Advance (CA), Cash on Delivery (COD), Cash Against Delivery (CAD)
  • Supply Ability
  • 25 Per Month
  • Delivery Time
  • 1 Week
  • Sample Available
  • Yes
  • Sample Policy
  • Within a certain price range free samples are available
  • Packaging Details
  • WOODEN BOX
  • Main Export Market(s)
  • Asia
  • Main Domestic Market
  • All India
  • Certifications
  • ATIRA AHMEDABAD
